Corrugated Paper Cup Sleeve Forming And Closing Machine 70-80PCS/MIN

Basic Information
Place of Origin: China
Brand Name: Shunda
Certification: CE
Model Number: SHUNDA-80A
Minimum Order Quantity: 1 SET
Packaging Details: wooden pallet for paper cup sleeve machine
Delivery Time: 25-35 working days after received your payment
Payment Terms: T/T or L/C, Western Union
Supply Ability: 20 SETS per month
Detail Information
Product Name: Paper Cup Sleeve Machine Speed: 70-80pcs/min
Material: Single/Double PE Coated Paper Control: PLC
Intelligent: Touch Screen Air Consumption: 0.5m³/min
Weight: 3000KG Machine Dimension: 2500*1800*1700mm
Highlight:

high speed paper cup machine

,

paper cup manufacturing machine


Product Description



Corrugated Paper Cup Sleeve Forming And Closing Machine 70-80PCS/MIN



Corrugated Paper Cup Sleeve Forming And Closing Machine 70-80PCS/MIN 0





Specifications:



MODEL

                   Paper Cup sleeve machine SHUNDA-80A

SPEED

                    70-80PCS/MIN

CUP SIZE

                    < 16OZ

MATERIAL

                    135-450GRAM

CONFIGURATION

                    ULTRASONIC&HOT AIR

OUTPUT

                    380V/220V,60HZ

AIR COMPRESSOR

                    0.5 M³/Min

NET WEIGHT

                    4 TONS

MACHINE SIZE

                    2500  ×1800 ×1700 MM

COUNTER SIZE

                    900 ×900 ×1760 MM

FOB SHANGHAI

                    32000 USD/SET





Whole Process



Double wall paper deliver →Double wall Cup forming →Paint Oil on paper bottom→Cup outside Bottom curl→

Outside Cup paint glue inside→Inside Cup drop→Cup tight part→compact the finished cup





Applications:



Produce for Coffee Cup.Paper Cup sleeve.



Corrugated Paper Cup Sleeve Forming And Closing Machine 70-80PCS/MIN 1







Machine Details



Corrugated Paper Cup Sleeve Forming And Closing Machine 70-80PCS/MIN 2



Corrugated Paper Cup Sleeve Forming And Closing Machine 70-80PCS/MIN 3





Introduce



Paper Cup Sleeve Machine each action for paper cup making independent function.The so-called debugging is realizing the function of reservation components in a reasonable, therefore all sales to
Customer equipment, our company has finished  debugging already. if there is any place in running the project change, need to be completely familiar with and master the medium-speed charter flights outside the performance, structure, principle, and commissioning.If special circumstances, should contact with the company.







Maintaince Notice



1). Equipment maintenance and maintenance throughout "maintenance and repair is complementary", to do is
Use truly, careful maintenance, make the equipment in good condition;


(2). Must work equipment and machine internal clean up debris and litter;


(3). Responsible for the maintenance personnel should be directly responsible for the equipment are in good condition, must understand equipment performance and principle, troubleshooting and maintenance,


(4) on the automatic lubrication system inspection every week, ensure that all assigned to each and every day oil flow;


(5). Half a month to the machine manual to filling of point injection, to do a good job of lubrication system.Including: gear, bearing, CAM, pendulum pole pin, clip agencies connecting rod, slider mechanism of lubrication.
