|Lid Size:||Diameter: 60mm-125mm Height:12-25mm||Raw Material:||135-450gsm|
|Lid size||Diameter(A): 60mm-125mm
|Material||Single and Double PE coated paper|
|Paper request Gram||135-450GSM(single and double PE coated paper)|
|Heating system||Hot air and electric heating|
|Output||380V/220V 5.5KW,50HZ, Three Phase four wire|
|Air compressor||1.2 M³/Min|
|Net weight||2 TONS|
|Machinery Size||1700 ×1300 ×1500 MM|
Finished products(Paper Lids only, customized):
· Horizontal machine design
· Gear Driven
· Advanced cylindrical cam indexing gear
· Automatic lubricating
· PLC closed-loop control system
· Touch-screen control
· Servo control for bottom feeding
Detailed pictures show:
Lid Body Sealing
Ultrasonic sealing for lid body, both okay for single or double pe coated paper.
Gear Drive System
1. Make running more stable
2. High Precision
Oil Lubrication System
1. automatic spray engine oil to gears, chains
2. less human maintaince
3. oil can be recyced used
4. clean and change oil half a year
PLC control Panel
Simple and efficient control panel, mady by MITSUBISHI
make work more intelligent.
Haining Chengda Paper Cup Machinery CO.,Ltd is established in year 1999,as Chinese earliest
paper cup machine manufacturer--design,research,manufacture,sell and serve , we have developed,
matured and specialized in machine types as below,
--Normal speed paper cup machine ZBJ-9A ZBJ-12A 45-50cups/min
--Middle speed paper bowl machine SMD-80B 70-80cups/min
--Middle speed double wall paper cup machine SMD-80A 70-80cups/min
--High speed paper cup machine SMD-90 100-130cups/min
With decade years of technology accumulation,advanced manufacturing skills and thoughtful after-sale
services, Chengda(Shunda) Paper Cup Machinery CO., Ltd has self-supported import and export right
and goes though CCC and CNAS certificates,also get CE and ISO9001 certified.
A QC team with more than 10 professional and technical personnel. To ensure 100% products checking.
Material: Strictly control of material using, meet international requested standards.
Semi-finished products inspection: Product inspection before 100% finished.
Production line test: With work team or data engineer who will inspect machines and lines at fixed period.
Finished Product Inspection: Quality and property test before products are packed and loaded.
