High Automation Paper Cups Making Machine For Ice Cream Cup 60HZ 12kw
Key Attributes
Product Summary
High Automation Paper Cups Making Machine For Ice Cream Cup 60HZ 12kw picture: detail: MODEL SMD-90 Speed 90-100cups/min Cup Size Range
Product Details
fully automatic paper cup making machine
,paper cup manufacturing machine
High Automation Paper Cups Making Machine For Ice Cream Cup 60HZ 12kw
picture:
detail:
| MODEL | SMD-90 |
| Speed | 90-100cups/min |
| Cup Size Range | <20oz |
| Material | Single and double PE coated paper |
| Heating system | Ultrasonic &hot air system |
| Output | 380V,11 KW ,60HZ, Three Phase four wire |
| Net weight | 3.4 TONS |
| Warranty | 3years |
| Paper request | 135gsm-450gsm |
| Description | smd-90 paper cup machine is a high gram paper cup shaping machine, it has high automation and high stability.The machine has photoelectric tracking system,can check every part and report.PLC control system make the machine more intellgent.open cylindrical cam and gear working make the machine running more quick and more stable,promote the long life . Used ultrasonic and two hot air for heating,advanced technology allowed facility more safty both on itself and operator.It is an ideal equipment to make the paper cups for hot drink, cold drink, and ice cream paper cups. |
customer:
FAQ
1. Q: Is your company a factory or trading company?
A: Our company is a factory.
2. Q:Where is your factory located? How can I visit there?
A:Our factory is located in haining City, Zhejiang Province, China, about 1.5 hours by car from
Shanghai .All our clients, from home or abroad, are warmly welcome to visit our company !
3. Q:How guarantee the quality of machine?
A:We promise the assemble and wormanship will be top class.Before the shipment, technologist
will adjust the machine until perfect performance.we support 3 years warranty and constant service,any question any time you can inquiry us on email or just call us.
