Electric High Speed Paper Cup Forming Machine For Single / Double PE Coated Paper

Electric High Speed Paper Cup Forming Machine For Single / Double PE Coated Paper
Electric High Speed Paper Cup Forming Machine For Single / Double PE Coated Paper Electric High Speed Paper Cup Forming Machine For Single / Double PE Coated Paper Electric High Speed Paper Cup Forming Machine For Single / Double PE Coated Paper Electric High Speed Paper Cup Forming Machine For Single / Double PE Coated Paper Electric High Speed Paper Cup Forming Machine For Single / Double PE Coated Paper Electric High Speed Paper Cup Forming Machine For Single / Double PE Coated Paper

Large Image :  Electric High Speed Paper Cup Forming Machine For Single / Double PE Coated Paper Get Best Price

Product Details:

Place of Origin: China
Brand Name: Shunda
Certification: CE
Model Number: SMD-90

Payment & Shipping Terms:

Minimum Order Quantity: 1 set paper cup machine
Price: negotiation
Packaging Details: wooden case
Delivery Time: 30-40 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 30 sets/month
Detailed Product Description
Speed: 100-120pcs/min(max 150pcs/min) Cup Size: 4-16oz
Material: 135-450gram(single And Double PE Coatede Paper) Color: Client Requirement
Configutraion: Ultrasonic&hot Air Output: 12KW,380V/220V,60HZ/50HZ
Air Compressor: 0.4 M³/Min 0.5MPA Net Weight: 3.4 TONS
Dimension Of Machine: 2500×1800×1700 MM Dimension Of Cup Collector: 900×900×1760 MM
High Light:

disposable cup making machine

,

machine for paper cup production


Electric High Speed Paper Cup Forming Machine For Single / Double PE Coated Paper​


Product Description of paper cup making machine


MODEL

SMD-90 PAPER CUP MACHINE

Speed

100-120 PCS/MIN(max 150pcs/min)

Cup size  Range

4-16oz

Material

Single  and  Double  PE coated paper

Paper request Gram

135-450GSM(single and double PE coated paper)

Heating  system

Hot air system (from Switzerland)

Output

380V/220V 12 KW,50HZ, Three Phase four wire

Air compressor

0.4 M³/Min

Net weight

3.4 TONS

Machinery Size

2500  ×1800 ×1700 MM

Counter Size

900 ×900 ×1760 MM



Paper cup making process

Details:



Open cylindrical cam: Our factory is the first one using two cam systems, this design more costly, but can let the top curling and bottom knurling more accuracy, stable and low noise. Cam adpots high strength Japan-SKD11 with quenching treatment,resistant to wear. Before set up on the machine, our factory will test running one week, to ensure each bearing at the suitable station.

Electric High Speed Paper Cup Forming Machine For Single / Double PE Coated Paper 1



Hot air system and protect system: 2 set of hot air systems can decrease the rate of leakage. Our factory using the whole set of Leister hot air system with protection system. And our system sets up on the fixed plate, do not moving during production. Almost impossible to damage. Also the only one have the protect system that hot parts will go down, keep the distance with paper cup and cup mould when the machine stop.

Electric High Speed Paper Cup Forming Machine For Single / Double PE Coated Paper 2



Paper fan side seal:Hot air system for preheating, using ultrasonic for side seal. Ensure no water leakage during high speed running. Especially for double PE coated paper fan, have two side hot air system. Ultrasonic is made in Taiwan by EVEN GREEN.

Electric High Speed Paper Cup Forming Machine For Single / Double PE Coated Paper 3





About us:
Haining Chengda Machinery Co.,LTd  always abides by the business strategy of "high quality products & reasonable price", the service concept of "showing respect to you & trying my best", and the professional spirit of ’’honesty, innovation, enthusiasm, sureness" to provide customers the best products and services. Make paper cup machine since 1998, ship to more than 100 countries.

about us.jpg





Advantages





  1. Quality assurance both for our products and service for after-sales.
  2. Favorable price.
  3. Great variety of products.
  4. Attractive design.
  5. Environment Friendly Technology
  6. OEM and ODM service provided.



Our QC team

A QC team with more than 10 professional and technical personnel. To ensure 100% products

checking.



Material: Strictly control of material using, meet international requested standards.



Semi-finished products inspection: Product inspection before 100% finished.



Production line test: With work team or data engineer who will inspect machines and lines at fixed period.



Finished Product Inspection: Quality and property test before products are packed and loaded.




FAQ
1. Q: Is your company a factory or trading company?
A: Our company is a factory.

2. Q:Where is your factory located? How can I visit there?
A:Our factory is located in haining City, Zhejiang Province, China, about 1.5 hours by car from Shanghai .All our clients, from home or abroad, are warmly welcome to visit our company !

3. Q:How does your factory do regarding quality control?
A:Quality is priority. Shunda people always attach great importance to quality controlling from the very beginning to the very end:
1).All raw material we used are environmental-friendly;
2).Skilful workers care every details in handling the producing and packing processes;
3).Quality Control Department specially responsible for quality checking in each process.
