High Speed Automatic Double Wall Mchine For Takeaway Coffee Cups With Inspection System

Good quality Paper Tea Cup Making Machine for sales
Good quality Paper Tea Cup Making Machine for sales
I love their machinery, pretty good quality. Their service is Amazing ,Big kiss To jenny~~

—— Mr. Hang Seng

I deal only with Shunda. Other haven't goid quality,i check other machine. First time using, U will have problem.

—— Rafik

I'm Online Chat Now

High Speed Automatic Double Wall Mchine For Takeaway Coffee Cups With Inspection System

China High Speed Automatic Double Wall Mchine For Takeaway Coffee Cups With Inspection System supplier
High Speed Automatic Double Wall Mchine For Takeaway Coffee Cups With Inspection System supplier High Speed Automatic Double Wall Mchine For Takeaway Coffee Cups With Inspection System supplier High Speed Automatic Double Wall Mchine For Takeaway Coffee Cups With Inspection System supplier High Speed Automatic Double Wall Mchine For Takeaway Coffee Cups With Inspection System supplier High Speed Automatic Double Wall Mchine For Takeaway Coffee Cups With Inspection System supplier High Speed Automatic Double Wall Mchine For Takeaway Coffee Cups With Inspection System supplier

Large Image :  High Speed Automatic Double Wall Mchine For Takeaway Coffee Cups With Inspection System

Product Details:

Place of Origin: China
Brand Name: Shunda
Certification: CE ISO9001
Model Number: SHUNDA-80A

Payment & Shipping Terms:

Minimum Order Quantity: 1 set double wall paper cup machine
Price: negotiable
Packaging Details: Standard seaworthy package, with PP film,wooden palte and wooden case
Delivery Time: 35-45 working days after confirmed cup size and received deposit
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 35 SETS per month
Contact Now
Detailed Product Description
Speed: 80-100cups/min Cup Size: 6-22oz
Paper Weight: 135-450gsm Seal Mode: Ultrasonic System & Hot Air
Control Mode: Mistubishi PLC Output: 10KW,380V/220V,60HZ/50HZ
Air Consumption: 0.4 M³/Min 0.5MPA Dimension Of Machine: 2500×1800 ×1700 MM
Dimension Of Cup Collector: 900 ×900 ×1760 MM Net Weight: 3.0 TONS



Double wall paper cup machine,high speed automatic double wall coffee paper cup sleeving machine





Specification



MODEL

      Paper Cup sleeve machine SHUNDA-80A

SPEED

                    70-80PCS/MIN

CUP SIZE

                    6-22OZ

MATERIAL

                    135-450GRAM

CONFIGURATION

                    ULTRASONIC&HOT AIR

OUTPUT

                    380V/220V,60HZ

AIR COMPRESSOR

                    0.4 M³/Min

NET WEIGHT

                    3 TONS

MACHINE SIZE

                    2500  ×1800 ×1700 MM

COUNTER SIZE

                    900 ×900 ×1760 MM

Drive mode

                   Open cylindrical cam





Description



Paper Cup Sleeve machine  is great thermal insulation container.
Our company developed fast speed double wall paper Cup machine, using Gear working, it has better promotion for noise,speed,stability .





Application



Coffee Cup double wall sleeve.



High Speed Automatic Double Wall Mchine For Takeaway Coffee Cups With Inspection System





Highlights



Paper fan side seal:Hot air system for preheating, using ultrasonic for side seal. Ensure no water leakage during high speed running. Especially for double PE coated paper fan, have two side hot air system.



High Speed Automatic Double Wall Mchine For Takeaway Coffee Cups With Inspection System

High Speed Automatic Double Wall Mchine For Takeaway Coffee Cups With Inspection System



Open cylindrical cam: Our factory is the first one using two cam systems, this design more costly, but can let the top curling and bottom knurling more accuracy, stable and low noise. Cam adpots high strength Japan-SKD11 with quenching treatment,resistant to wear. Before set up on the machine, our factory will test running one week, to ensure each bearing at the suitable station.



High Speed Automatic Double Wall Mchine For Takeaway Coffee Cups With Inspection System



All mouldings are after heat treat, 10 years usage is garuanteed.

High Speed Automatic Double Wall Mchine For Takeaway Coffee Cups With Inspection System



Quality control



1).All parts are strictly inspected before assemblied onto machine.



2).10 year experience assembly workers,always follow standard quality rules.



3). 3 years warranty promise, 7 day 24 hour online/phone service availble.



High Speed Automatic Double Wall Mchine For Takeaway Coffee Cups With Inspection System







Locate us -- 1.5 hours by car from Shanghai Pudong Airport.



High Speed Automatic Double Wall Mchine For Takeaway Coffee Cups With Inspection System
