Paper Bowl Making Machine,automatic paper bowl making machine 80pcs/min digital control

Basic Information
Place of Origin: China
Brand Name: Shunda
Certification: CE,ISO9001
Model Number: SHUNDA-80B
Minimum Order Quantity: 1 set paper bowl machine
Price: negotiable
Packaging Details: Standard seaworthy package
Delivery Time: 35-45 working days after confirmed bowl size and received deposit
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 18 sets per month
Detail Information
Product: Paper Bowl Making Machine Color: As Per Requirement
Cuo Size: 2-32oz Speed: 70-80 Pcs/min
Raw Material: 135-450GRAM Configuration: ULTRASONIC&HOT AIR
Output: 380V/220V,60HZ Air Compressor: 0.4 M³/Min 0.5MPA
Dimension Of Machine: 2500×1800 ×1700 MM Dimension Of Cup Collector: 900 ×900 ×1760 MM
High Light:

disposable cup thermoforming machine

,

fully automatic paper cup machine


Product Description



Paper Bowl Making Machine,automatic paper bowl making machine 80 pcs/min digital control





Specification



MODEL

                    SHUNDA-80B

SPEED

                 70-80 PCS

CUP SIZE

                    2-32 oz

MATERIAL

                    135-450GRAM

CONFIGURATION

                    ULTRASONIC&HOT AIR

OUTPUT

                    380V/220V,60HZ





Process of paper bowl making machine



Paper Bowl Making Machine,automatic paper bowl making machine 80pcs/min digital control 0





Bowl size range



top diameter 9-15cm

bottom diameter 6-11.5cm

height 5-13.5cm




Description

SMD-80B is a paper bowl machine,which is designed By HAINING CHENGDA MACHINERY CO.,LTD,It can produce both single and Double PE coated paper Bowls. As technology development, it will take place of the formally machines in market day by day.


Hot air system and protect system: 2 set of hot air systems can decrease the rate of leakage. Our factory using the whole set of Leister hot air system with protection system. And our system sets up on the fixed plate, do not moving during production. Almost impossible to damage. Also the only one have the protect system that hot parts will go down, keep the distance with paper cup and cup mould when the machine stop.



Paper Bowl Making Machine,automatic paper bowl making machine 80pcs/min digital control 1


Mitsubishi PLC tracking and Touch screen Controlling cabinet



Paper Bowl Making Machine,automatic paper bowl making machine 80pcs/min digital control 2


Servo motor: Service for bottom paper feeding. The feature of runs more stable and accuracy, reduce
the waste of bottom paper. Servo motor is made in Japan by MITSUBISHI.





Paper Bowl Making Machine,automatic paper bowl making machine 80pcs/min digital control 3


Automatic lubrication system



Paper Bowl Making Machine,automatic paper bowl making machine 80pcs/min digital control 4


Safety Door opening protection device



Paper Bowl Making Machine,automatic paper bowl making machine 80pcs/min digital control 5


Photoelectric detection: each production step have camera. Any step have problem will be showed on PLC. Such as the stock of paper fan less than standard, will be alarming. If do not add paper fan, will finish paper fan in machine firstly,then, stop the machine automaticly.





Paper Bowl Making Machine,automatic paper bowl making machine 80pcs/min digital control 6


Automatic collecting and counting cups





FAQ



1. Q: Is your company a factory or trading company?

A: Our company is a factory since year 1998.

2. Q:Where is your factory located? How can I visit there?

A: Our factory is located in haining City, Zhejiang Province, China, about 80 minutes by car from Shanghai airport.



Paper Bowl Making Machine,automatic paper bowl making machine 80pcs/min digital control 7





After Service


Warranty:3 years--all machines adjusted to proper working condition before shipping.



Instruction manual and engneer drawings will be sent together with machine.



Oversea installation service is available,however reasonable flight cost,accommodation and daily salary is requested.





Package



PP film to be waterproof,then wooden plate,and fixed into wooden case.
