Large Image :  Paper Bowl Making Machine,ultrasonic sealing paper cup machine ice cream bowl,popcorn bowl

Product Details:

Place of Origin: China
Brand Name: Shunda
Certification: CE,ISO9001
Model Number: SHUNDA-80B

Payment & Shipping Terms:

Minimum Order Quantity: 1 set paper bowl machine
Price: negotiable
Packaging Details: Export wood case,20ft can load 2 sets of machine
Delivery Time: 35-45 working days after confirmed bowl size and received deposit
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100 SETS per month
Contact Now
Detailed Product Description
Product: Paper Tea Cup Making Machine Speed: 70-80 Pcs/min
Size: 2-32oz Paper Fan: 135-450gsm
Configuration: ULTRASONIC & HOT AIR SYSTEM Output: 380V/220V,60HZ/50HZ, 14KW
Air Compressor: 0.4 M³/Min 0.5MPA Net Weight: 3.4 TONS
Dimension Of Machine: 2500×1800 ×1700 MM Dimension Of Cup Collector: 900 ×900 ×1760 MM



Paper Bowl Making Machine,ultrasonic sealing paper cup machine ice cream bowl,

popcorn bowl





Specification



MODEL SHUNDA-80B
SPEED 70-80 PCS
CUP SIZE 2-32 oz
MATERIAL 135-450GRAM
CONFIGURATION ULTRASONIC&HOT AIR
OUTPUT 380V/220V,60HZ





Process of paper bowl making machine

Paper Bowl Making Machine,ultrasonic sealing paper cup machine ice cream bowl,popcorn bowl





Bowl size range



top diameter 9-15cm

bottom diameter 6-11.5cm

height 5-13.5cm




Description

SMD-80B is a paper bowl  machine,which is designed By HAINING CHENGDA MACHINERY CO.,LTD,It can produce both single and Double PE coated paper Bowls. As technology development, it will take place of the formally machines in market day by day.


Hot air system and protect system: 2 set of hot air systems can decrease the rate of leakage. Our factory using the whole set of Leister hot air system with protection system. And our system sets up on the fixed plate, do not moving during production. Almost impossible to damage. Also the only one have the protect system that hot parts will go down, keep the distance with paper cup and cup mould when the machine stop.



Paper Bowl Making Machine,ultrasonic sealing paper cup machine ice cream bowl,popcorn bowl


Mitsubishi PLC tracking and Touch screen Controlling cabinet



Paper Bowl Making Machine,ultrasonic sealing paper cup machine ice cream bowl,popcorn bowl


Servo motor: Service for bottom paper feeding. The feature of runs more stable and accuracy, reduce the waste of bottom paper. Servo motor is made in Japan by MITSUBISHI.



Paper Bowl Making Machine,ultrasonic sealing paper cup machine ice cream bowl,popcorn bowl




Oil lubrication system: Adoptes forced lubrication system to ensure main driving oil supply regularly and reduce friction and prolong the machine life. The oil circuit adds a clear the oil and filtering system to clean the oil automaticly. Our factory is the first one to using double layer plate to avoid the scraps of paper into the machine's inside.



Paper Bowl Making Machine,ultrasonic sealing paper cup machine ice cream bowl,popcorn bowl



Safe door: Set up safe door and security button. Keep safe. Two type of design can be selected.



Paper Bowl Making Machine,ultrasonic sealing paper cup machine ice cream bowl,popcorn bowl


Photoelectric detection: each production step have camera. Any step have problem will be showed on PLC. Such as the stock of paper fan less than standard, will be alarming. If do not add paper fan, will finish paper fan in machine firstly,then, stop the machine automaticly.



Paper Bowl Making Machine,ultrasonic sealing paper cup machine ice cream bowl,popcorn bowl


Automatic collecting and counting cups





FAQ



1. Q: Is your company a factory or trading company?

A: Our company is a factory since year 1998.

2. Q:Where is your factory located? How can I visit there?

A: Our factory is located in haining City, Zhejiang Province, China, about 80 minutes by car from Shanghai airport.



Paper Bowl Making Machine,ultrasonic sealing paper cup machine ice cream bowl,popcorn bowl





After Service


Warranty:3 years--all machines adjusted to proper working condition before shipping.



Instruction manual and engneer drawings will be sent together with machine.



Oversea installation service is available,however reasonable flight cost,accommodation and daily salary is requested.





Package



PP film to be waterproof,then wooden plate,and fixed into wooden case.
