| Place of Origin: | China |
|---|---|
| Brand Name: | Shunda |
| Certification: | CE ISO9001 |
| Model Number: | SMD-80B |
| Minimum Order Quantity: | 1 set paper bowl machine |
| Price: | negotiable |
| Packaging Details: | Seaworthy standard package |
| Delivery Time: | 21 working days after received your payment |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 18 sets per month |
| Product Name: | Paper Bowl Making Machine | Speed: | 70-80 Pcs/min |
|---|---|---|---|
| Top Diameter: | 90mm(min)-150mm(max) | Height: | 60mm(min)-115mm(max) |
| Bottom Diameter: | 50mm(min)-135mm(max) | Raw Material: | 135-450 GRAM |
| Configuration: | ULTRASONIC&HOT AIR | Standard: | CE/SGS |
| Output: | 380V/220V,60HZ/50HZ, 14KW | Air Compressor: | 0.4 M³/Min 0.5MPA |
| Net Weight: | 3.4 TONS | Color: | As Per Requirement |
| High Light: | fully automatic paper cup machine,automatic paper cup forming machine |
||
Paper Bowl Making Machine,digital high speed paper bowl making machine 50ml to 900ml
Specification
MODEL | SMD-80A |
SPEED | 70-80 PCS/MIN |
MAX CUP SIZE | Diameter: 90mm(min)-150mm(max) |
MATERIAL | 135-450GRAM |
CONFIGURATION | ULTRASONIC&HOT AIR |
OUTPUT | 380V/220V,60HZ/50HZ, 14KW |
AIR COMPRESSOR | 0.4 M³/Min 0.5MPA |
NET WEIGHT | 3.4 TONS |
MACHINE SIZE | 2500 ×1800 ×1700 MM |
COUNTER SIZE | 900 ×900 ×1760 MM |
Description
SMD-80B is a paper bowl machine,which is designed By HAINING CHENGDA MACHINERY CO.,LTD,It can produce both single and Double PE coated paper Bowls. As technology development, it will take place of the formally machines in market day by day.
1. Hi-tech Cylindrical indexing gear
2. Hot air system and protect system: 2 set of hot air systems can decrease the rate of leakage. Our factory using the whole set of Leister hot air system with protection system. And our system sets up on the fixed plate, do not moving during production. Almost impossible to damage. Also the only one have the protect system that hot parts will go down, keep the distance with paper cup and cup mould when the machine stop.
3. Mitsubishi PLC tracking and Touch screen Controlling cabinet
4. Servo motor: Service for bottom paper feeding. The feature of runs more stable and accuracy, reduce the waste of bottom paper. Servo motor is made in Japan by MITSUBISHI.
5. Automatic lubrication system
6. Infinitely variable drive
7. Safety Door opening protection device
8. Photoelectric tracking and detecting every step
9. Automatic collecting and counting cups
Process of paper bowl making machine
Bowl size range
top diameter 9-15cm
bottom diameter 6-11.5cm
height 5-13.5cm
FAQ
1. Q: Is your company a factory or trading company?
A: Our company is a factory since year 1998.
2. Q:Where is your factory located? How can I visit there?
A: Our factory is located in haining City, Zhejiang Province, China, about 80 minutes by car from Shanghai airport.
After Service
Warranty:3 years--all machines adjusted to proper working condition before shipping.
Instruction manual and engneer drawings will be sent together with machine.
Oversea installation service is available,however reasonable flight cost,accommodation and daily salary is requested.
Package
PP film to be waterproof,then wooden plate,and fixed into wooden case.
