Payment & Shipping Terms:
|Capacity:||80-100 Cups/min||Sealing Pattern:||Evergreen/Genuode Ultrasonic System|
|Waster Collecting Pattern:||Automatic Cutting System||Paper Fan Weight Range:||135g--450g|
|Air Compressor:||0.4 M³/Min 0.5MPA||Output:||10KW,380V/220V,60HZ/50HZ|
|Packing Weight:||3000 Kg||Colors:||As Per Requirements|
|Dimension Of Machine:||2500×1800 ×1700 MM||Dimension Of Cup Collector:||900 ×900 ×1760 MM|
Hollow Double Wall Paper Cup Machine , Max 100 Cups Per Minute
|MODEL||SMD-80A Double Wall PAPER CUP MACHINE|
|Cup size Range||6-22 oz|
|Material||Single and Double PE coated paper|
|Paper request Gram||135-450GSM(single and double PE coated paper)|
|Heating system||Hot air system (from Switzerland)|
|Output||380V/220V 10 KW,50HZ, Three Phase four wire|
|Air compressor||0.4 M³/Min|
|Net weight||3 TONS|
|Machinery Size||2500 ×1800 ×1700 MM|
1.It has 2 sets of original imported hot air system Leister guarantee the stability of heating.
2.Ultrasonic seal the paper cup body,can produce both single and double PE coated paper.
3.Open cylindrical can divide locating,heigh precision.
4.Automatically Oil lubrication system .
5.Servo motor control the gap of the bottom-paper within 0.1mm.
6.Gear and open cylindrical promote the stability and speed.
Output Count :
|Normal Running Speed||90 pcs/min||50 pcs/min||40 pcs|
|1 Day(12 Hours)||90pcs*60min*12hours=64800 pcs||50pcs*60min*12hours=36000 pcs||28800pcs|
|1 Week (5 Days)||64800pcs*5days=324000pcs||36000pcs*5days=180000pcs||144000pcs|
|1 Mouth(22 Days)||64800pcs*22days=1425600pcs||360000pcs*22days=792000pcs||633600pcs|
Haining Chengda Paper Cup Machinery CO.,Ltd is established in year 1999,as Chinese earliest paper cup machine manufacturer--design,research,manufacture,sell and serve , we have developed, matured and specialized in machine types as below,
--Middle speed paper bowl machine SMD-80B 70-80cups/min
--Middle speed double wall paper cup machine SMD-80A 80-100cups/min
--High speed paper cup machine SMD-90 100-120cups/min
With decade years of technology accumulation,advanced manufacturing skills and thoughtful after-sale services, Chengda(Shunda) Paper Cup Machinery CO., Ltd has self-supported import and export right and goes though CCC and CNAS certificates,also get CE and ISO9001 certified.
We have been supported hundreds of paper cup factories around the globe,especially enjoy high reputation in USA,Finland,Algeria,etc.
We are always holding the faith of “quality wins market,honest wins trust”.And in the future
we should increase technology creation,focus on improving manufacturing skills and lead trend of paper cup machine industry.
1. Q: Is your company a factory or trading company?
A: Our company is a factory.
2. Q:Where is your factory located? How can I visit there?
A:Our factory is located in haining City, Zhejiang Province, China, about 1.5 hours by car from Shanghai .All our clients, from home or abroad, are warmly welcome to visit our company !
3. Q:How does your factory do regarding quality control?
A:We hold firm faith that quality comes first,and promise 3 YEARS warranty.
Because our debuggers test and adjust every machine for 1 week before packing and shipping out of workshop, no compromises on quality.
1.warranty: 3 year
2.the guide booklet will be sent with machine to guide the installation process works,adjust
the whole machine,production,avoide or solve the problem which the buyer will face.
3.we will adjust the machine well for one week before the delivery,ensure the machine has
the perfect performance.
4.we can dispatch technologists to buyer's factory,guiding installation,ajustment for a
period,the buyer incharge of the salary,traffic fee,boarding and lodging,communication and each day 100usd living allowances.
5.we supply the free training of buyer,the training won't stop until the buyer control the whole lesson!
6.we supply the consumable spare parts for frees for three year use.
Contact Person: Joie Xu
